GATE DA Machine Learning Formula Sheet with Worked Lines

Q: What is the formula for information gain in a decision tree?

Information gain is the parent's entropy minus the weighted entropy of the children: H(parent) - Σ (| child |)/(| parent |) H(child), with H = - Σ pₖ log₂ pₖ. Entropy is 1 bit for a 50-50 split of two classes and 0 for a pure node. Use log₂, because the answer is expected in bits.

Q: How many parameters does a fully connected neural network have?

For layers of sizes n₀, n₁, …, nL, count Σₗ nₗ₋₁ nₗ weights, then add one bias for every unit after the input layer. A 4-3-1 network has 12 + 3 = 15 weights and 4 biases, so 19 parameters. Questions often ask for weights only, so read whether biases are included.

Q: What is the margin of a hard-margin SVM?

The hard-margin SVM minimises 1/2lVert w rVert² subject to yᵢ(w^(top) xᵢ + b) ≥ 1, and the width of the margin is 2/(lVert w rVert). The support vectors lie exactly on yᵢ(w^(top) xᵢ + b) = 1. Removing a point that is not a support vector leaves the solution unchanged, a fact worth knowing for statement-based questions.

Q: What is the difference between k-fold and leave-one-out cross-validation?

In k-fold cross-validation you split the data into k folds, train k models each on k - 1 folds, and average the validation scores. Leave-one-out is the case k = n: it trains n models, each on n - 1 points. It is nearly unbiased but expensive and has high variance. Never tune on the test set.

Q: How do you compute the variance explained by a principal component?

Centre the data and find the eigenvalues of its covariance matrix. The variance along component k is its eigenvalue λₖ, and the share explained is λₖ/(Σⱼ λⱼ). With eigenvalues 6, 3 and 1, the first component explains 60 per cent and the first two explain 90 per cent. PCA is sensitive to feature scaling.

By MD ANISH AHAMADUpdated 4 Oct 20266 min read

GATE DA Machine Learning Formula Sheet with Worked Lines

The machine learning formulas you need for GATE DA cover regression, classification, decision trees, neural networks, model selection, clustering and PCA. This sheet gives each with its condition, a one-line example of my own and the trap beside it. Every formula is checked against the last-minute sheet in the GATE DA 2027 book.

In this guide

Key takeaways
The terms this sheet uses
Regression
Classification: logistic, Bayes, LDA and SVM
Trees and evaluation
Neural networks and model selection
Clustering and PCA
Using the sheet in the exam
Quick revision

Key takeaways

Least squares, ridge and PCA are linear algebra: learn the matrix forms, not only the scalar ones.
Ridge shrinks coefficients towards zero but never exactly to zero.
Logistic regression, LDA with a shared covariance and the perceptron all draw linear boundaries.
Entropy in bits uses $\log_2$ ; the logistic loss uses $\ln$ .
Small $k$ in k-nearest neighbour means high variance; large $k$ means high bias.
Count network parameters layer by layer, and check whether biases are included.

The terms this sheet uses

The training data are $n$ pairs $(x_i, y_i)$ . Each $x_i$ is a vector of features, and $y_i$ is its label: a number in regression, a class in classification. $X$ is the $n \times d$ matrix of features, one row per example.

A model has a weight vector $w$ and a bias $b$ . The loss measures how wrong the predictions are, and training minimises it. $\eta$ is the learning rate. $\ln$ is the natural logarithm, and $\log_2$ is used wherever the answer is in bits.

Regression

Formula	Watch out for
$\hat{y} = \beta_0 + \beta_1 x$ ; $\displaystyle \beta_1 = \frac{\sum (x_i - \bar{x})(y_i - \bar{y})}{\sum (x_i - \bar{x})^2}$ ; $\beta_0 = \bar{y} - \beta_1 \bar{x}$	The line passes through $(\bar{x}, \bar{y})$
Through the origin: $\displaystyle w = \frac{\sum x_i y_i}{\sum x_i^2}$	No centring here
$\displaystyle R^2 = 1 - \frac{SS_{\text{res}}}{SS_{\text{tot}}}$	Simple regression: $R^2 = r^2$
$X^\top X\beta = X^\top y$ , so $\hat{\beta} = (X^\top X)^{-1}X^\top y$	Fitted values $Hy$ , $H = X(X^\top X)^{-1}X^\top$ is a projection
Ridge: minimise $\lVert y - X\beta \rVert^2 + \lambda \lVert \beta \rVert^2$ ; $\hat{\beta} = (X^\top X + \lambda I)^{-1}X^\top y$	Invertible for every $\lambda > 0$
Larger $\lambda$ : smaller coefficients, more bias, less variance	Never exactly zero; $\lambda = 0$ is least squares

Examples: for $x = (1, 2, 3)$ and $y = (2, 3, 5)$ , $\displaystyle \beta_1 = \frac{3}{2} = 1.5$ and $\displaystyle \beta_0 = \frac{10}{3} - 3 = \frac{1}{3}$ . Through the origin with $x = (1, 2)$ and $y = (2, 3)$ , $\displaystyle w = \frac{8}{5} = 1.6$ ; ridge with $\lambda = 1$ gives $\displaystyle \frac{8}{5 + 1} \approx 1.33$ . If $SS_{\text{res}} = 20$ and $SS_{\text{tot}} = 80$ , then $R^2 = 0.75$ .

Trap: The intercept is usually not penalised in ridge regression. Shrinking it would move the fitted line away from the data's mean.

Classification: logistic, Bayes, LDA and SVM

Formula	Watch out for
$P(y = 1 \mid x) = \sigma(w^\top x + b)$ ; $\displaystyle \ln\frac{p}{1 - p} = w^\top x + b$	The boundary is linear
Loss $-\sum \big[y_i \ln p_i + (1 - y_i)\ln(1 - p_i)\big]$ ; gradient $\sum (p_i - y_i)x_i$	No closed-form solution
Naive Bayes: $P(C \mid x) \propto P(C)\prod_j P(x_j \mid C)$	Features independent given the class
$K$ binary features, two classes: $2K + 1$ parameters	$2K$ likelihoods plus one prior, since the two priors sum to 1
Laplace: $\displaystyle P(x_j = v \mid C) = \frac{\text{count} + 1}{N_C + \text{number of values of } x_j}$	Removes zero probabilities
Bayes error at $x$ : $1 - \max_C P(C \mid x)$	Choose the largest posterior
LDA with a shared covariance: linear boundary	Unequal covariances give a quadratic one
Fisher: maximise $\displaystyle J(w) = \frac{w^\top S_B w}{w^\top S_W w}$ ; two classes $w \propto S_W^{-1}(\mu_1 - \mu_2)$	At most $C - 1$ directions for $C$ classes
Perceptron: if $y_i(w^\top x_i + b) \le 0$ , $w \leftarrow w + \eta y_i x_i$ , $b \leftarrow b + \eta y_i$	Converges iff linearly separable
SVM margin $\displaystyle \frac{2}{\lVert w \rVert}$ ; $w = \sum \alpha_i y_i x_i$ , $\alpha_i > 0$ only on support vectors	Large $C$ allows little slack

Examples: if $w^\top x + b = 2$ , then $\displaystyle P(y = 1 \mid x) = \frac{1}{1 + e^{-2}} \approx 0.881$ . Ten binary features with two classes need 21 naive Bayes parameters. A value never seen in 8 examples of a class with 2 possible values gets $\displaystyle \frac{0 + 1}{8 + 2} = 0.1$ . With $w = (3, 4)$ , the SVM margin is $\displaystyle \frac{2}{5} = 0.4$ .

The k-nearest neighbour rule takes a majority vote of the $k$ closest points. With $k = 1$ the training error is zero. Scale the features first, and pick an odd $k$ to avoid ties between two classes. XOR is not linearly separable, so no perceptron learns it; one hidden layer does.

Trees and evaluation

Formula	Watch out for
$H = -\sum_k p_k \log_2 p_k$	1 bit at 50-50, 0 when pure
$\text{Gini} = 1 - \sum_k p_k^2$	0.5 at 50-50 for two classes
Gain $\displaystyle = H(\text{parent}) - \sum \frac{\lvert \text{child} \rvert}{\lvert \text{parent} \rvert}H(\text{child})$	Weight children by size
Accuracy $\displaystyle \frac{TP + TN}{\text{total}}$ ; precision $\displaystyle \frac{TP}{TP + FP}$ ; recall $\displaystyle \frac{TP}{TP + FN}$	Do not swap FP and FN
$\displaystyle F_1 = \frac{2PR}{P + R}$ ; specificity $\displaystyle \frac{TN}{TN + FP}$	$F_1$ is a harmonic mean

Examples: a parent with 4 positive and 4 negative examples has $H = 1$ . Split into $(3+, 1-)$ and $(1+, 3-)$ , each child has $H \approx 0.811$ , so the gain is about 0.189. With $TP = 40$ , $FP = 10$ and $FN = 20$ : precision 0.8, recall $\displaystyle \frac{2}{3}$ , $F_1 \approx 0.727$ .

The book's last-minute sheet covers all seven technical sections in this form, each result with its condition beside it. It is in the GATE DA 2027 book, with 907 questions with worked solutions and 10 full mock tests.

Neural networks and model selection

Formula	Watch out for
$a = g(w^\top x + b)$ ; ReLU $g(z) = \max(0, z)$	Derivative 1 for $z > 0$ , 0 for $z < 0$
Sigmoid $\sigma' = \sigma(1 - \sigma)$	At most $\displaystyle \frac{1}{4}$
No non-linearity: $W_2 W_1 x$ is one linear layer	Depth alone adds nothing
Weights $\sum_l n_{l-1}n_l$ ; biases $\sum_{l \ge 1} n_l$	No bias on the input layer
$\displaystyle \frac{\partial L}{\partial w} = (\text{error at output unit}) \times (\text{activation at input unit})$	Errors flow back through $W^\top$ times $g'$
$w \leftarrow w - \eta \nabla L(w)$ ; with $\displaystyle \frac{1}{2}(\hat{y} - y)^2$ : $w \leftarrow w - \eta(\hat{y} - y)x$	Without the $\displaystyle \frac{1}{2}$ , a factor 2 appears
Expected squared error $= \text{bias}^2 + \text{variance} + \text{noise}$	Flexible models: low bias, high variance
k-fold: $k$ models, each on $k - 1$ folds; leave-one-out: $n$ models on $n - 1$ points	Never tune on the test set

Examples: a 4–3–1 network has $12 + 3 = 15$ weights and 19 parameters. One step with $w = 1$ , $x = 2$ , $y = 3$ , $\eta = 0.1$ and loss $\displaystyle \frac{1}{2}(\hat{y} - y)^2$ gives $\hat{y} = 2$ and $w = 1 - 0.1 \times (-1) \times 2 = 1.2$ . Five-fold validation on 100 points trains 5 models, each on 80 points.

Remember: Regularisation trades a little bias for less variance. That one sentence answers most bias–variance statements about ridge, $k$ in k-NN and tree depth.

Clustering and PCA

Formula	Watch out for
k-means minimises $\sum \lVert x - \mu_{c(x)} \rVert^2$	Never increases; local optimum depends on the start
k-medoids: centres are data points, any dissimilarity	Less sensitive to outliers
Agglomerative: $n - 1$ merges from $n$ singletons	Divisive works top-down
Single linkage: minimum pair distance; complete: maximum; average: mean	Single linkage chains
Euclidean $\sqrt{\sum (x_i - y_i)^2}$ ; Manhattan $\sum \lvert x_i - y_i \rvert$	The metric can change the first merge
PCA: eigenvectors of $\displaystyle S = \frac{1}{n}X^\top X$ on centred $X$ ; share $\displaystyle \frac{\lambda_k}{\sum_j \lambda_j}$	Centre first; scaling matters
Scores $z = W^\top(x - \bar{x})$ ; via SVD, $\displaystyle \lambda = \frac{\sigma^2}{n}$	Components are orthogonal

Examples: from $(0, 0)$ to $(3, 4)$ the Euclidean distance is 5 and the Manhattan distance 7. Eigenvalues 6, 3 and 1 give shares of 0.6, 0.3 and 0.1.

In one line: PCA is an eigenvalue problem on the centred covariance matrix, so the linear algebra sheet does half the work.

Using the sheet in the exam

Entropy, $F_1$ and sigmoid values end in decimals. Practise them on the GATE virtual calculator. When a set of statements comes as a multiple-select question, judge each one separately. The MCQ, MSQ and NAT marking scheme, common to every GATE paper, gives an MSQ no partial credit and no negative marks. If you know the CS syllabus, GATE CS vs GATE DA shows that machine learning is DA's own territory. How a raw mark becomes a score is in GATE score calculation and normalisation.

More formula sheets: all of GATE DA · DBMS and Algorithms · Linear Algebra and Calculus · Probability and Statistics

Quick revision

$\displaystyle \beta_1 = \frac{S_{xy}}{S_{xx}}$ , and the line passes through $(\bar{x}, \bar{y})$ .
Ridge: $(X^\top X + \lambda I)^{-1}X^\top y$ , shrinking but never to zero.
Naive Bayes multiplies the prior by each feature's likelihood given the class.
SVM margin is $\displaystyle \frac{2}{\lVert w \rVert}$ ; only support vectors matter.
Entropy uses $\log_2$ ; Gini is $1 - \sum p_k^2$ .
Precision divides by $TP + FP$ , recall by $TP + FN$ .
Weights $\sum n_{l-1}n_l$ , plus one bias per non-input unit.
PCA share of component $k$ is $\displaystyle \frac{\lambda_k}{\sum_j \lambda_j}$ .

Frequently asked questions

What is the formula for information gain in a decision tree?

Information gain is the parent's entropy minus the weighted entropy of the children: $\displaystyle H(\text{parent}) - \sum \frac{\lvert \text{child} \rvert}{\lvert \text{parent} \rvert} H(\text{child})$ , with $H = -\sum p_k \log_2 p_k$ . Entropy is 1 bit for a 50-50 split of two classes and 0 for a pure node. Use $\log_2$ , because the answer is expected in bits.

How many parameters does a fully connected neural network have?

For layers of sizes $n_0, n_1, \ldots, n_L$ , count $\sum_l n_{l-1} n_l$ weights, then add one bias for every unit after the input layer. A 4-3-1 network has $12 + 3 = 15$ weights and 4 biases, so 19 parameters. Questions often ask for weights only, so read whether biases are included.

What is the margin of a hard-margin SVM?

The hard-margin SVM minimises $\displaystyle \frac{1}{2}\lVert w \rVert^2$ subject to $y_i(w^\top x_i + b) \ge 1$ , and the width of the margin is $\displaystyle \frac{2}{\lVert w \rVert}$ . The support vectors lie exactly on $y_i(w^\top x_i + b) = 1$ . Removing a point that is not a support vector leaves the solution unchanged, a fact worth knowing for statement-based questions.

What is the difference between k-fold and leave-one-out cross-validation?

In k-fold cross-validation you split the data into $k$ folds, train $k$ models each on $k - 1$ folds, and average the validation scores. Leave-one-out is the case $k = n$ : it trains $n$ models, each on $n - 1$ points. It is nearly unbiased but expensive and has high variance. Never tune on the test set.

How do you compute the variance explained by a principal component?

Centre the data and find the eigenvalues of its covariance matrix. The variance along component $k$ is its eigenvalue $\lambda_k$ , and the share explained is $\displaystyle \frac{\lambda_k}{\sum_j \lambda_j}$ . With eigenvalues 6, 3 and 1, the first component explains 60 per cent and the first two explain 90 per cent. PCA is sensitive to feature scaling.
