GATE EE Power Electronics Formula Sheet: Key Formulas and Traps

The key GATE EE power electronics formulas are the converter gains $D$, $1/(1 - D)$ and $-D/(1 - D)$, the rectifier averages in $\cos\alpha$ or $(1 + \cos\alpha)$, the commutation times $\pi\sqrt{LC}$ and $CV/I$, power factor as distortion factor times displacement factor, and the inverter fundamentals. Each holds only under a stated condition, usually continuous conduction. This sheet teaches them in learning order, each with a worked example and its trap.

Key takeaways

• Every DC-DC converter result comes from volt-second balance, charge balance and power balance.
• The converter gains hold only in continuous conduction, so check the inductance against its critical value first.
• Rectifier averages use the peak voltage $V_m$, while supplies are quoted as RMS, so convert once at the start.
• A fully controlled converter inverts above 90 degrees; a semi-converter never can.
• With a sinusoidal supply only the fundamental current carries power.
• Inverter questions separate waveform RMS from fundamental RMS, and phase values from line values.

The terms this sheet uses

Most lost marks come from misreading a symbol, so fix the notation first. The duty ratio $D = t_{on}/T$ is the fraction of each switching period for which the switch is on; $f = 1/T$ is the switching frequency.

The firing angle $\alpha$ is the delay from the instant a thyristor becomes forward-biased to the instant its gate is pulsed. A diode acts like a thyristor fired at $\alpha = 0$.

$V_m$ is always a peak: a supply of $V$ RMS has $V_m = \sqrt{2}\,V$. For a three-phase bridge, $V_{mL}$ is the line peak and $V_L$ the line RMS.

Continuous conduction means the inductor or load current never reaches zero in a cycle. $I_d$ is a ripple-free DC load current, held level by a large inductor. The overlap angle $\mu$ is the extra commutation angle caused by source inductance.

How each switching device behaves and where its losses come from

A thyristor turns on with a gate pulse once forward-biased, and turns off only when its current falls below the holding current and reverse voltage is held for longer than its turn-off time $t_q$. In speed, the MOSFET leads, then the IGBT, the GTO and the SCR.

Losses come from a straight-line on-state model: a fixed drop $V_0$ in series with a resistance $r$. The drop multiplies the average current; the resistance multiplies the squared RMS current.

Worked example. A diode with $V_0 = 0.8$ V and $r = 10\ \text{m}\Omega$ carries 30 A pulses at one-third duty: $I_{avg} = 10\ \text{A},\ I_{rms}^2 = 900/3 = 300,\ P = 0.8 \times 10 + 0.01 \times 300 = 11\ \text{W}$.

The trap is using 10 A in both terms, which gives 9 W. Pulsed current heats the resistance more than its average suggests.

DC-DC converters: gains, ripple and the edge of continuous conduction

In steady state the inductor voltage averages to zero over a period, which is volt-second balance, and the capacitor current averages to zero, which is charge balance. Add the lossless power balance $V_{in} I_{in} = V_o I_o$ and the whole table follows.

Ripples are peak to peak. The critical inductance is the value at which the inductor current just touches zero each period; below it, conduction is discontinuous.

Worked example (buck). With $V_{in} = 24$ V, $D = 0.5$, $f = 100$ kHz, $L = 60\ \mu$H, $C = 10\ \mu$F and $R = 6\ \Omega$: $\displaystyle V_o = 12\ \text{V},\ I_o = 2\ \text{A},\ \Delta I_L = \frac{12 \times 0.5}{60 \times 10^{-6} \times 10^{5}} = 1\ \text{A},\ I_{L,\min} = 1.5\ \text{A} > 0,\ \Delta V_o = \frac{1}{8 \times 10^{-5} \times 10^{5}} = 0.125\ \text{V}$.

Worked example (boost). With $V_{in} = 12$ V, $D = 0.6$, $R = 30\ \Omega$ and $f = 50$ kHz: $\displaystyle V_o = \frac{12}{0.4} = 30\ \text{V},\ I_L = \frac{1}{0.4} = 2.5\ \text{A},\ L_{crit} = \frac{0.6 \times 0.16 \times 30}{2 \times 50000} = 28.8\ \mu\text{H}$.

Trap: The three gains belong to continuous conduction only. If the inductor current falls to zero in each cycle, discard them and write volt-second and power balance from the waveform you are given.

Many questions run backwards: they give a current waveform and ask for $L$, $C$ or the source voltage. Read each slope as $V = L\,\Delta I/\Delta t$.

Uncontrolled rectifiers: averages from the peak voltage

A diode rectifier is a thyristor rectifier fired at $\alpha = 0$. Each average is the area under the output voltage divided by the period.

Worked example. A 50 V battery charges through $10\ \Omega$ from a half-wave rectifier with $V_m = 100$ V: $\displaystyle \theta_1 = 30^\circ,\ I_{avg} = \frac{2 \times 100 \times 0.866 - 50 \times 2\pi/3}{2\pi \times 10} = \frac{173.2 - 104.7}{62.83} = 1.09\ \text{A}$.

The trap is the peak in the three-phase bridge. On 400 V, $3\sqrt{2} \times 400/\pi = 540.2$ V; using the phase peak gives a figure $\sqrt{3}$ times too small.

Controlled rectifiers: firing angle, inversion and overlap

Delaying the firing by $\alpha$ removes a slice of each output pulse. With continuous current, a fully controlled converter follows $\cos\alpha$; a semi-converter follows $(1 + \cos\alpha)$ because its freewheeling path clamps the output at zero.

Worked example. A single-phase full converter on 230 V at $\alpha = 60^\circ$, with $\omega L_s = 1\ \Omega$ and $I_d = 10$ A: $\displaystyle V_{dc} = 207.1 \times 0.5 - \frac{2 \times 1 \times 10}{\pi} = 103.5 - 6.4 = 97.2\ \text{V},\ \cos(60^\circ + \mu) = 0.5 - \frac{20}{325.3} = 0.4385,\ \mu \approx 4.0^\circ$.

Remember: Regeneration needs a negative average voltage at positive current. A fully controlled converter gives it above 90 degrees with a reversed DC source; a semi-converter never can.

Commutation: turning a thyristor off

In line (voltage) commutation the AC supply reverses the thyristor voltage, as in every rectifier above. In forced (current) commutation a charged capacitor or an LC ring drives the current to zero.

Worked example. With $L = 40\ \mu$H, $C = 10\ \mu$F and 100 V on an uncharged capacitor: $\pi\sqrt{LC} = \pi \times 20\ \mu\text{s} = 62.8\ \mu\text{s},\ I_{peak} = 100\sqrt{10/40} = 50\ \text{A}$.

Worked example. A $20\ \mu$F capacitor at 100 V commutating 40 A: $\displaystyle t_c = \frac{20 \times 10^{-6} \times 100}{40} = 50\ \mu\text{s} > t_q = 30\ \mu\text{s}$.

The AC controller trap is firing below the load angle. With $R = 10\ \Omega$ and $\omega L = 17.32\ \Omega$, $\phi = 60^\circ$, so firing at $30^\circ$ acts like firing at $60^\circ$.

Line-current harmonics, distortion factor and displacement factor

A rectifier with a large inductive load draws a block-shaped line current. Fourier analysis splits it into a fundamental and harmonics. With a sinusoidal supply only the fundamental does work; harmonics add RMS current but no power.

Worked example. An 8 A fundamental lagging $36.87^\circ$ plus a 6 A fifth harmonic: $I_s = \sqrt{64 + 36} = 10\ \text{A},\ \text{DF} = 0.8,\ \text{THD} = 0.75,\ \text{PF} = 0.8 \times 0.8 = 0.64$.

Worked example. A semi-converter with $I_d = 10$ A at $\alpha = 90^\circ$: $\displaystyle I_s = 10\sqrt{0.5} = 7.07\ \text{A},\ I_{s1} = 0.9003 \times 10 \times 0.7071 = 6.37\ \text{A},\ \text{PF} = \frac{6.37}{7.07} \times 0.7071 = 0.637$.

In one line: Add the squared harmonic RMS values for the total, divide the fundamental by it, then multiply by the cosine of the fundamental's own phase angle.

Inverters and sinusoidal PWM: fundamentals, phase and line

An inverter turns a DC bus into AC. In square-wave mode you need the Fourier series of a fixed pattern; in sinusoidal PWM a modulation index scales the fundamental.

Worked example. Three-phase SPWM with $V_{dc} = 400$ V and $m_a = 0.9$: $\displaystyle \hat{V}_{ph} = \frac{0.9 \times 400}{2} = 180\ \text{V},\ V_{ph} = \frac{180}{\sqrt{2}} = 127.3\ \text{V},\ V_L = \sqrt{3} \times 127.3 = 220.5\ \text{V}$.

Worked example. A 120 V full bridge feeding 40 mH at 50 Hz: $\displaystyle \Delta I = \frac{120 \times 0.02}{2 \times 0.04} = 30\ \text{A}$ peak to peak, from $-15$ A to $+15$ A.

The trap is mixing waveform RMS with fundamental RMS. A 200 V full bridge has 200 V output RMS but only 180.1 V fundamental, and only that fundamental delivers power to a sinusoidal current.
